تفاصيل المنتج:
|
| معيار: | ASTM ، AISI ، DIN ، EN ، GB ، JIS | مكان المنشأ: | جيانغسو ، الصين (البر الرئيسي) |
|---|---|---|---|
| استخدام خاص: | فولاذ صمام | مادة: | الفولاذ المقاوم للصدأ |
| شكل: | دائري | سطح: | أسود، مشرق، طحن |
| إبراز: | ASTM A479 stainless steel round bar,TP321 stainless steel solid rod,DIN1.4541 black surface steel bar,TP321 stainless steel solid rod,DIN1.4541 black surface steel bar |
||
Specifications of Stainless Steel Round Bright Bar 303 304 316L 321 316Ti 431 :
|
Stainless Steel Materials
|
Stainless Steel Bright Round Bar |
| Stainless Grades | 303F/303Cu/304/304L/304F/316/316L/316F/2520/310/2507/416/630/17-4/431/321 |
| Standard | ASTM,AISI,DIN,EN,GB,JIS |
| Production Standard | ASTM A276, ASTM A582, ASTM A484 |
| Round Bar | Dia: 6mm - 250mm |
| Polish: HR annealed & pickled, HR &Round turned, centerless ground & polish, cold drawn& polished, Soomth tured & polished | |
| Hex Bar | AF: 8mm - 75mm |
| Polish: Cold drawn bright, Annealed, Shot blasting, Sand blasting | |
| Square Bar | AF: 3*10mm - 75*120mm |
| Polish: Cold drawn bright, Annealed, Shot blasting, Sand blasting | |
| Flat Bar | T*W: 8*8mm - 75*95mm |
| Polish: Cold drawn bright, Annealed, Shot blasting, Sand blasting | |
| Inspections | MTC (chemical composition, Mechanical Property), SGS, The Third Party |
| Tolerance | H9, H11, L12 |
| Roundness | +/-0.02mm |
| Roughness | 240 Grits |
| Staightness | 0.01mm/1Meter |
| Stainless steel bar long | As clients's requirements |
| Application | Precision machined components, Screw machined products, CNC turning/mill products, Shaft, Automotive components, Medical and Aerospace and electronic components |
| Production capacity | 200 Tons/ Month |
| Samples | Available, 2 days |
| MOQ | 500KGS (can be mixed sizes) |
| Delivery time | A.7 days if this goods is stock goods. |
| B.20 days if this goods will be produced after order |
| Region | Standard | Grade Code |
|---|---|---|
| USA | ASTM A276 | UNS S32100 |
| Europe | EN 1.4541 | X6CrNiTi18-10 |
| China | GB/T 1220 | 06Cr18Ni11Ti |
| Japan | JIS SUS 321 | - |
| International | ISO 15510 | X7CrNiTi18-10 |
| Element | Content | Functional Role |
|---|---|---|
| Titanium (Ti) | ≥5×C% (min.) | Prevents chromium carbide formation during welding/heat exposure |
| Chromium (Cr) | 17.0–19.0% | Forms heat-resistant chromium oxide layer |
| Nickel (Ni) | 9.0–12.0% | Stabilizes structure under cyclic thermal loads |
| Carbon (C) | ≤0.08% | Controlled for weld integrity |
| Iron (Fe) | Balance | Matrix foundation |
Mechanical Properties
Tensile Strength: 515–720 MPa (solution-annealed)
Creep Resistance: 120 MPa at 600°C (1.000-hour rupture)
Thermal Cycling Tolerance: 200+ cycles (ambient to 800°C)
Hardness: 70–90 HRB (annealed), customizable via cold drawing
Max Service Temp: 900°C (intermittent), 700°C (continuous)
Thermal Expansion: 17.3 μm/m·K (20–100°C)
Oxidation Threshold: Up to 925°C in dry air
Magnetic Response: Non-magnetic post-annealing
Heat War Veteran:
Outperforms 304/316 in cyclic heating (e.g., kiln fixtures, jet engine mounts).
Weld Zone Guardian:
Titanium neutralizes carbon, eliminating post-weld decay risks.
Corrosion Arsenal:
Resists sulfuric/nitric acids, steam, and thermal oxidation scaling.
Fatigue Resistance:
30% higher stress-cycle endurance vs. non-stabilized grades.
Sustainability Plus:
85% recycled content; RoHS/REACH compliant.
| Industry | Transformative Uses |
|---|---|
| Aerospace | Combustion chamber liners, turbine shafts |
| Automotive | High-temp exhaust manifolds, EGR components |
| Chemical | Catalyst grids, pyrolysis tubes |
| Power Generation | Boiler tubes, superheater supports |
| Additive Manufacturing | High-purity powder feedstock for 3D printing |
