تفاصيل المنتج:
|
| الصف الصلب: | سبيكة الصلب | سبيكة أم لا: | سبيكة |
|---|---|---|---|
| تقنية: | المدرفلة على الساخن ، المسحوب على البارد | طلب: | أداة شريط الصلب |
| يكتب: | 50CrV4 | معيار: | ASTM ، DIN |
| استخدام خاص: | الصلب العفن | شكل: | دائري |
| طول: | 1 م - 6 م | سطح: | أسود أو مشرق |
| اسم المنتج: | 42crmo4 qt سبائك الصلب قضبان مستديرة | قطر: | 12 مم -650 مم |
| حالة التسليم: | محترق، خلال 15 يوما بعد استلام الودائع | أبعاد: | 5-900 مم |
| المعالجة الحرارية: | تطبيع + صلب + مروي + خفف | ||
| إبراز: | 51CrV4 alloy steel round bar,50CrVA spring steel rod,ASTM AISI SAE 6150 steel bar,50CrVA spring steel rod,ASTM AISI SAE 6150 steel bar |
||
Alloy steels are designated by AISI four-digit numbers. They are more responsive to mechanical and heat treatments than carbon steels. They comprise different types of steels with compositions which exceed the limitations of B, C, Mn, Mo, Ni, Si, Cr, and Va in the carbon steels.
| Technical parameters | |
| Material | 51CrV4 steel round bar |
| Size | Diameter:5mm-1000mm |
| Length:3000mm-6000mm | |
| Origin place | Made In China |
| Delivery Condition | Hot rolled,cold drawn,forged |
| Surface require | Black,grinding,bright,polish,turn,peel |
| Heat treatment | Quenched,Tempered,annealed |
| Packing | seaworthy packing,wooden case,carton,woven bag or at client's requires |
| Delivery time | In 10-50 days |
| Trade Term | EXW,FOB,CIF |
| Payments | T/T or L/C at sight |
| Port | China main Port,such as shanghai, Dalian, shenzhen port. |
| AISI | GB/T | DIN | DIN | C | Si | Mn | P | S | Ni | Cr | Mo | V |
| 4118 | 20CrMo | 18CrMo4 | 1.7243 | 0.18-0.23 | 0.15-0.35 | 0.70-0.90 | ≤ 0.035 | ≤ 0.035 | - | 0.4-0.6 | 0.08-0.15 | - |
| 4130 | 30CrMo | 25CrMo4 | 1.7218 | 0.28-0.33 | 0.15-0.35 | 0.40-0.60 | ≤0.035 | ≤ 0.040 | - | 0.80-1.10 | 0.15-0.25 | - |
| 4135 | 35CrMo | 34CRMO4 | 1.722 | 0.33-0.38 | 0.15-0.35 | 0.70-0.90 | ≤ 0.035 | ≤ 0.040 | - | 0.80-1.10 | 0.15-0.25 | - |
| 4140 | 42CrMo | 42CrMo4 | 1.7225 | 0.38-0.43 | 0.15-0.35 | 0.75-1.00 | ≤ 0.035 | ≤ 0.040 | - | 0.80-1.10 | 0.15-0.25 | - |
| 4340 | 40CrNiMo | 36CrNiMo4 | 1.6563 | 0.38-0.43 | 0.15-0.35 | 0.60-0.80 | ≤ 0.035 | ≤ 0.040 | 1.65-2.00 | 0.70-0.90 | 0.20-0.30 | - |
| 5115 | 15CrMn | 16MnCr5 | 1.7131 | 0.14-0.19 | ≤ 0.4 | 1.0-1.30 | ≤ 0.025 | ≤ 0.035 | - | 0.80-1.10 | - | - |
| 5120 | 20Cr | 20Cr4 | 1.7016 | 0.17-0.22 | 0.15-0.35 | 0.7-0.9 | ≤0.035 | ≤ 0.040 | - | 0.70-0.90 | - | - |
| 5120 | 20CrMn | 20MnCr5 | 1.7147 | 0.17-0.22 | 0.15-0.40 | 1.1-1.4 | ≤ 0.025 | ≤ 0.035 | - | 1.0-1.3 | - | - |
| 5140 | 40Cr | 41Cr4 | 1.7035 | 0.38-0.43 | 0.15-0.35 | 0.7-0.9 | ≤ 0.035 | ≤ 0.040 | - | 0.70-0.90 | - | - |
| 6150 | 50CrV | 51CrV4 | 1.8159 | 0.48-0.53 | 0.15-0.35 | 0.70-0.90 | ≤ 0.035 | ≤ 0.040 | - | 0.80-1.10 | - | ≥0.15 |
| 8620 | 20CrNiMo | 21NiCrMo2 | 1.6523 | 0.18-0.23 | 0.15-0.35 | 0.7-0.9 | ≤ 0.035 | ≤ 0.040 | 0.4-0.7 | 0.4-0.6 | 0.15-0.25 | - |
We Have State Of The Art Production Lines With Leading Edge Technology For Bearing Steel 100Cr6, Stainless Steel 304 / 316 / Duplex UNS S31803 And Super Duplex UNS S3276, Alloy Steel 4130/4140/8620, High Speed Tool T1/M2/M35/M42 And Die Steel D2/D3/H13/H21/P20. The Products Covers Special Steel Round, Square, Flat, Wire Rod, Wire, Sheet, Pipe, Strip And Heavy Forgings. Produces Forged Round Steel (¢120~850mm) And Square Steel (120~550mm) Of Various Steel Grades.
|
Alloy Steel
|
4140,4142,42CrMo4,1.7225,SCM440,4130,SCM430,25CrMo4,1.7218,34CrNiMo6,
1.6582,4340,SNCM439,36CrNiMo4,1.6511,SACN645,1340,SMn438,SNC236 |
|||
|
Tool Steel
|
H13,1.2344,SKD61,D2,SKD11,1.2379,1.2510,01,SKS3,95MnWCr5,D3,SKD1,1.2419,
SKS31,H21,SKD5,1.2581,P20,35CrMo7,1.2738,1.2316,M2 |
|||
|
Bearing Steel
|
GCr15,52100,SUJ1,SUJ2,100Cr6,1.2067,55C,8620,4320,9310,440C,M50
|
|||
|
Spring Steel
|
9260,SUP6,SUP7,1.7108,54SiCr6,1.7102,5155,SUP9,1.7176,5160,1.7177,6150,
SUP10,51CrV4,1.8159 |
|||
|
Stainless Steel
|
321,sus321,1.4541,304,SUS304,1.4301,410,SUS410,1.4006,420,1.4021,1.4028,
434,1.4113,316L,SUS316L,1.4435,630,1.4542,431,1.4057 |
|||
